Thanks to the very compact size of this Linux computer, it can be mounted behind a monitor or TV using the included VESA bracket.
Intel NUC10i3FNH Core i3 Linux Mini-Pc
$ 413,81 ($ 413,81 Excl. VAT)
This Intel NUC10i3FNH with a 10th gen. Core i3 processor, is a full featured workstation in a compact size. The Intel® UHD Graphics offer a brilliant 4K resolution experience for home or office use. This Mini-Pc is easy to mount to a monitor with Vesa.
Less than 4cm in height
This even more compact but comprehensive Intel Mini-Pc features the latest Intel Core i3 processor, up to 64GB of DDR4 memory, USB-C with Thunderbolt, HDMI and has Wireless AX/AC. All in a package of just 117mm x 112mm x 51mm.
Intel NUC10i3FNK Features
- Intel® Core™ i3-10110U Processor
- Intel® UHD Graphics
- 2x DDR4 SO-DIMM slots (up to 64 GB, 2666 MHz)
- Intel® Wi-Fi 6 AX201 and Bluetooth
- 2x front USB (Type-A, Type-C), 3x rear USB 3.1 Gen2 (2x Type-A, Type-C with Thunderbolt 3);
- SD card slot
- 3.5mm stereo headphone front jack
- Power button on the front panel
- Support for third-party covers
- DC (12-19V) power connector
- HDMI 2.0a port incl. 8 channel audio (7.1 surround sound)
- Gigabit (1000/100/10MB) LAN
- DisplayPort 1.2 via Thunderbolt™ 3 / USB-C™ port
This NUC features the latest generation Intel i3 processor, Intel UHD Graphics for 4K resolution, M.2 PCIe SSD and DDR4 memory.
Due to the energy-efficient Intel processor and the use of an M.2 PCIe SSD, this NUC is definitely energy efficient (Power max. 90 Watts).
Configure this Linux mini
This Linux mini can be assembled with or without hardware (memory, storage, etc.) and operating system. If you assemble the Linux mini with hardware, the Linux mini will be custom assembled by us.
Questions about the specifications below? Contact our customer service directly.
|Processor*||Intel Core i3-10110U (2 Cores / 4 Threads) – 2.10GHz (Turbo 4.10 GHz) – 4MB Cache – TDP 15W|
Intel Core i5-10210U (4 Cores / 8 Threads) – 1.60GHz (Turbo 4.20 GHz) – 6MB Cache – TDP 15W
Intel Core i7-10710U (6 Cores / 12 Threads) – 1.10GHz (Turbo 4.70 GHz) – 12MB Cache – TDP 15W
|Memory*||2x DDR4 slots (expandable up to 64 GB SODIMM / maximum 2666MHz)|
We are using Kingston HyperX DDR4 2666MHz memory modules.
|Graphic card||Intel® UHD Graphics|
|Storage*||1 x 2.5″ (7mm) SATA HDD support|
1 x M.2 2280 PCIe Gen3x4 / SATA interface
We use the latest generation Samsung EVO (Plus) M.2 and 2.5inch SSDs and Seagate Barracuda HDDs.
|Sound||Intel High Definition Audio|
Built-in Microphone and Stereo Speakers (we disable the built-in microphone through hardware)
|Connections||SD card reader – MMC – RSMMC – MS Pro – MS Duo|
1x HDMI 2.0b with HDCP
1x USB-C (USB 3.1 Gen 2)
1x USB-C (USB 3.1 Gen 2) (Thunderbolt 3: DisplayPort output supported)
3x USB 3.0 (USB3.1 Gen 1)
1x RJ45 Gigabit Ethernet LAN connection (10/100/1000MB)
1x 3.5mm Headphone/Microphone jack
|Communications||Gigabit LAN (10/100/1000MB)|
Intel AX201 802.11AX dual-band 2.4 and 5.0 Ghz + Bluetooth V5.1
|Power||90W AC Adapter 100~240V, 50~60Hz, DC output 19V, 2.1A|
|Dimensions||117 mm x 112 mm x 51 mm|
Weight: 1.3 kg **
*Hardware depending on configuration.
**Weight dependent on configuration. Weight tolerance is about 5%.
